How to Choose a House Plan

Choosing a house plan is one of the most consequential decisions you'll make before breaking ground. Get it right and the whole build flows more smoothly. Get it wrong and you're paying an architect to redo work, or worse, living with a layout you don't like for twenty years.

This guide walks you through the process step by step, from sizing up your lot to reading the fine print on a stock plan purchase. No drafting experience needed.

Start with Your Lot, Not Your Dream Home

Most people start by browsing floor plans online and fall in love with something that won't fit their property. Save yourself the heartbreak: understand your lot constraints first.

Know Your Setbacks

Every municipality sets rules about how close a building can sit to property lines. These are called setbacks. A typical suburban lot might require 25 feet (7.6 m) from the front property line, 5 feet (1.5 m) on each side, and 20 feet (6.1 m) from the rear. Those setbacks carve out the "buildable envelope," the zone where the footprint can actually go.

Get the setback requirements for your specific parcel from your local building or planning department before you shop for plans. This is not something to guess at.

Check Lot Width Against Plan Width

House plans list the overall width and depth of the footprint. Before you pay for a plan, confirm the footprint fits inside your buildable envelope with room to spare. A 60-foot-wide (18.3 m) plan on a lot with 5-foot (1.5 m) side setbacks needs at least 70 feet (21.3 m) of lot width. Measure your lot on the county assessor's parcel map, or better yet, get a survey.

Think About Orientation

Which direction will the house face? North-south orientation affects passive solar gain, window placement, and where you'll want shaded outdoor spaces. A plan drawn for a south-facing lot may need to be mirrored to work on your site. Most plan sellers offer a reverse or mirror option, sometimes for a small fee.

Figure Out the Square Footage You Actually Need

Bigger is not automatically better. A 2,800 sq ft (260 m²) house costs more to build, heat, cool, and clean than a 1,800 sq ft (167 m²) house. Before browsing, write down the rooms you genuinely need and a rough size for each.

A simple sizing exercise:

Space	Minimum workable	Comfortable
Master bedroom	180 sq ft (17 m²)	240 sq ft (22 m²)
Secondary bedroom	100 sq ft (9.3 m²)	140 sq ft (13 m²)
Full bathroom	50 sq ft (4.6 m²)	60 sq ft (5.6 m²)
Kitchen	100 sq ft (9.3 m²)	160 sq ft (14.9 m²)
Living/great room	200 sq ft (18.6 m²)	320 sq ft (29.7 m²)
2-car garage	400 sq ft (37.2 m²)	480 sq ft (44.6 m²)

Add up your list, tack on 15% for hallways, closets, and mechanical space, and you have a realistic target range. How Square Footage Is Calculated explains exactly what counts toward the advertised number on a plan sheet, which can differ from what you'd expect.

Stock Plans vs. Custom Plans

When most people shop online, they're looking at stock plans: ready-made designs sold to multiple buyers. The alternative is hiring an architect or designer to create a custom set from scratch.

Stock Plans

Stock plans cost a fraction of custom work, typically $700 to $2,500 for a complete set of drawings. The tradeoff is that the plan was designed for a generic site and a generic buyer. You may need to pay extra for:

• A structural engineer to stamp the drawings for your local code (many jurisdictions require a local stamp even on stock plans)
• Modifications to the plan to meet local energy codes, wind loads, seismic requirements, or specific lot conditions
• A "wet-stamped" set if the plan service only sells PDF or digital files

Always confirm what your local building department requires before you buy. A plan that ships as a PDF may need to be redrawn by a local professional before a permit can be issued. Costs vary significantly by region, so call your permit office first.

Custom Plans

If your lot is irregular, steeply sloped, or has unusual constraints, a stock plan may not work without expensive modifications. At that point, a custom design often makes more sense economically. Custom fees vary widely by region and the complexity of the project. A licensed architect or designer can scope the work and give you a fee estimate.

What to Look For in a Plan Set

Once you've narrowed your search to plans that fit your lot and square footage target, dig into the actual drawings before you buy.

The Floor Plan

The floor plan is a top-down cut view showing room sizes, wall locations, doors, windows, and stairs. Look for:

• Traffic flow. Can you get from the garage to the kitchen without crossing the living room? Is the path from the master bedroom to a bathroom clear at 2 a.m.?
• Bedroom separation. If you want the master suite private from children's rooms, check that hallways or a common area separates them.
• Storage. Count the closets. Many plans are light on storage in the name of open layouts.
• Future flexibility. Is there a room that could serve as a home office, guest room, or nursery depending on your life stage?

Space Planning Basics for Beginners covers the concepts behind good room arrangement and helps you evaluate whether a plan's layout will actually work for daily life.

The Elevations

Elevations show the exterior faces of the house from each compass direction. Check that the exterior style matches your neighborhood requirements and your own taste. Some HOAs or local design review boards restrict exterior materials or roof pitches. Confirm any such rules before buying a plan.

Foundation Type

Plans are typically drawn for one of three foundation types: slab, crawl space, or full basement. Make sure the plan's foundation matches what's practical on your lot. Slab foundations are common in warm climates with stable soils. Full basements are common in colder northern climates. Building a full basement in a high-water-table area, or a crawl space on expansive clay soil, adds cost and risk.

Roof Pitch and Framing

Steeper roof pitches (say, 8:12 or higher, meaning the roof rises 8 inches for every 12 inches of horizontal run) increase material and labor costs but are often required to shed heavy snow loads. Check that the plan's roof pitch makes sense for your climate. This information appears in the roof plan and sometimes in the section drawings.

What a Plan Purchase Includes (and Doesn't)

Before you hand over payment, read the license terms. Stock plan purchases typically give you the right to build the design a specified number of times (usually once). They do not give you the copyright to the drawings or the right to resell them.

Check what file formats are included. A PDF-only package may be fine if your local permit office accepts PDFs. If you need to make modifications, a CAD file (DWG or DXF format) is much easier to work with. Some sellers charge more for the CAD files, which is worth it if changes are likely.

Also confirm whether the package includes:

• Electrical plans
• Plumbing rough-in diagrams
• HVAC layouts
• Structural details and beam schedules

Some budget plan packages omit these sheets. Your permit office and contractors will want them.

Modifications: What's Easy, What's Expensive

Small changes to a stock plan, such as flipping it to a mirror image, relocating a non-load-bearing wall, or adjusting window placement, are straightforward. Large changes get expensive fast:

• Moving a kitchen or bathroom changes all the plumbing rough-in locations
• Changing a roof type (hip to gable, for example) may require new structural calculations
• Adding or removing a floor changes foundation and structural loads throughout

If you find yourself wanting to change more than 20% of a plan, consider whether a different stock plan or a custom design would be more cost-effective. A good rule of thumb: if the changes would require a structural engineer's review anyway, price a custom design before committing to modify a stock plan. For a deeper look at putting your own ideas on paper, see How to Design Your Own House Plan.

Before You Build: The Steps Between "I Have Plans" and "I Have Permits"

Buying a set of plans is not the same as being ready to build. Here is the typical sequence after purchase:

1. Local code review. Have a local architect, engineer, or experienced contractor review the plans against your jurisdiction's current code. Requirements for insulation values, wind uplift, and seismic bracing change by location.
2. Site-specific adaptations. A civil engineer or surveyor may need to produce grading, drainage, and utility plans for your specific parcel.
3. Structural stamp. Many jurisdictions require a licensed structural engineer to review and stamp the structural drawings before a permit is issued. The stock plan seller's engineer stamp is from their home state and is often not accepted elsewhere.
4. Permit submission. Submit the full drawing package to your local building department. Plan check timelines vary from a few days to several months depending on the jurisdiction and workload.

Always confirm what your local building department requires before spending money on plans. Requirements vary significantly by region and change over time.

Frequently Asked Questions

Can I use a stock house plan in any state or country?

Stock plans are drawn to general building principles, but building codes, energy requirements, wind loads, and seismic zones differ significantly by location. A plan designed and stamped by an engineer in one state will usually need to be reviewed and restamped by a licensed professional in your state before a local permit office will accept it. Check with your local building department before buying.

How many sets of plans do I need for a permit application?

Requirements vary. Some jurisdictions accept digital PDF submissions. Others want two, three, or more full-size paper sets. Call your permit office before printing anything, as full-size architectural prints (typically 24x36 inches or 600x900 mm) are expensive to reproduce.

What does it mean when a plan says it can be "modified"?

It means the seller will alter the drawings for you, for an additional fee. Minor changes (like adding a window or shifting an interior wall) are usually affordable. Major structural changes can cost as much as a new custom design. Get a quote before committing.

Do I need an architect if I buy a stock plan?

You may need a licensed architect or engineer to review and adapt the drawings for your site and local code, even if you do not hire one to design the plan from scratch. Some states require an architect's seal on any residential drawings submitted for permit; others do not. Your local building department can tell you exactly what credentials the plan preparer must have.

How do I know if a plan fits my budget?

The square footage is the biggest cost driver, but layout efficiency matters too. A compact plan with simple rooflines and a rectangular footprint is cheaper to build per square foot than a sprawling plan with multiple roof planes, bump-outs, and complex framing. Ask a local builder or estimator to give you a ballpark cost per square foot in your area before committing to a plan size.
